Samway P32 Hose Crimping Machine

P32 HOSE CRIMPING MACHINE

TECHNICAL DATA
Crimping range in mm: 10 - 87 mm
Crimping range in inches: 0,39 - 3,42
Crimping force in metric tons: 200
Crimping force in kN: 2800
Maximum hose size in inches: 2"
Die Set: P32
Maximum travel of dies in mm: 33 mm

System Power: 4KW SIEMENS
Master die Diam. /Lenght in mm: 99 / 80
Master die Diam. /Lenght in inches: 3,90 / 3,15
Machine control: Manual
Colour: Blue

DIMENSIONS
Depth: 400 mm
Width: 850 mm
Height: 530 mm

DESIGNATION
Samway P32 : 9028-00-17 Order Number

DEI SET  (Standard die sets included)

P32-14: 9060-32-14
P32-16: 9060-32-16
P32-19: 9060-32-19
P32-22: 9060-32-22
P32-26: 9060-32-26
P32-30: 9060-32-30
P32-34: 9060-32-34
P32-39: 9060-32-39
P32-45: 9060-32-45
P32-51: 9060-32-51
P32-57: 9060-32-57
P32-63: 9060-32-63
P32-69: 9060-32-69

This machine come with the quick change system as standard.

Eaton Main Swith

German Rexroth pump and valve

Finnpower P32 Micro Dailer

SIEMENS Motor ( for 380-480v 3 phase model)

NOK Seals

SKD61 die sets vacumme heattreated
