SAMWAY SCC8068 Crawler Crane

Home
Crawler Cranes
SAMWAY SCC8068 Crawler Crane

SAMWAY SCC8068 Crawler Crane

Price:

sales@samway.com

SKU:

SAMWAY SCC8068 Crawler Crane

Brand:

Samway

Weight:

N/A

Availability:

SAMWAY SCC8068 Crawler Crane

Product Description

SAMWAY SCC8068 Crawler Crane

• Cov cav: Cummins QSC8.3, 245 hp @ 2000 rpm

• Kaw lus hydraulic: Rexroth twj thiab tsav motors

• Tsim SAMWAY LMI nrog tshuaj ntsuam muaj zaub ntau heev

• Lem extendable

• Ob configurations muaj: Boom loj thiab Jib taag

• Main boom m Tubular thiab kaum sab xis siv

TSEEM CEEB NTA

Ntau tau @ voos kheej-kheej	75 U.S. T @ 12.5 ft
Lub ntsiab Boom	3,6 & 9 Meter Sections 42 ft 8 in. – 219 ft 10 in.
Max taub qhov siab (H ntsiab Boom)	223 ft
Taag Jib ntev	29 ft 6 in. – 59 ft 1 in.
Winch tseem ceeb - nyob kab rub	20,944 lb
Txoj kab uas hla hlua hlau	24 mm
Yuag Theem pib siv lub tshuab (tsis khiav ntas & cov Boom taub qab)	99,206 lb
Tag nrho Counterweight (Series 2)	82,450 lb
Ntev Yooj yim tshuab - thauj (uas khiav ntas & Boom taub qab)	43 ft 4 in.
Qhov siab Yooj yim tshuab - thauj (uas khiav ntas & Boom taub qab)	11 ft 5 in.
Dav Yooj yim tshuab - thauj (uas khiav ntas & Boom taub qab)	11 ft 4 in.
Tw viav	16 ft 5 in

QHOV NTEV THAUJ

	NYIAJ siv lub TSHUAB (uas khiav num)
	Ntev	43'4"
	Dav	11'4"
	Qhov siab	11'5"
	Yuag	99206 lb

	NYIAJ siv lub TSHUAB (tsis khiav num)
	Ntev	26'2"
	Dav	11'
	Qhov siab	10'
	Yuag	55115 lb

	KHIAV NUM
	Ntev	20'8"
	Dav	3'7"
	Qhov siab	3'11"
	Yuag	20944 lb

	PUAG BOOM
	Ntev	22'1"
	Dav	5'3"
	Qhov siab	7'2"
	Luj Tubular Boom	3726 lb
	Luj lub Boom	3748 lb

	NTSIS BOOM
	Ntev	23'4"
	Dav	5'3"
	Qhov siab	5'9"
	Luj Tubular Boom	3241 lb
	Luj lub Boom	3190 lb

	NTXIG BOOM 9'10 "(3m)
	Ntev	10'4"
	Dav	5'6"
	Qhov siab	5'5"
	Luj Tubular Boom	1014 lb
	Luj lub Boom	1378 lb

	Ib tsab ntawv nrog thaum BOOM 19'8 "(6m)
	Ntev	20'2"
	Dav	5'3"
	Qhov siab	5'5"
	Luj Tubular Boom	1631 lb
	Luj lub Boom	2173 lb

	Tsab ntawv nrog thaum BOOM 29'6 "(9m) No. 1
	Ntev	30'
	Dav	5'3"
	Qhov siab	5'5"
	Luj Tubular Boom	2072 lb
	Luj lub Boom	3057 lb

	Tsab ntawv nrog thaum BOOM 29'6 "(9m) No. 2
	Ntev	30'
	Dav	5'3"
	Qhov siab	5'5"
	Luj Tubular Boom	2072 lb
	* Tsis muaj nyob hauv lub Boom

	TAAG JIB ntsis 14'9 "(4.5 m)
	Ntev	16'
	Dav	2'10"
	Qhov siab	2'6"
	Yuag	728 lb

	TAAG JIB puag 14'9 "(4.5 m)
	Ntev	15'6"
	Dav	2'11"
	Qhov siab	2'6"
	Yuag	661 lb

	TAAG JIB INSERT 14'9 "(4.5 m)
	Ntev	15'
	Dav	2'10"
	Qhov siab	2'6"
	Yuag	507 lb

	QAUM TAW TES BOOM
	Ntev	6'2"
	Dav	2'5"
	Qhov siab	2'1"
	Luj Tubular Boom	375 lb
	Luj lub Boom	375 lb

	CRAWLER SAB COUNTERWEIGHT
	Ntev	12'5"
	Dav	1'3"
	Qhov siab	2'5"
	Yuag	11023 lb

	UPPERWORKS COUNTERWEIGHT TAIS
	Ntev	14'1"
	Dav	5'3"
	Qhov siab	2'
	Yuag	22046 lb

	COUNTERWEIGHT THAIV
	Ntev	4'6"
	Dav	3'7"
	Qhov siab	2'7"
	Yuag	6393 lb

	NUV thaiv 55 USt (50 Mt)
	Ntev	6'6"
	Dav	2'9"
	Qhov siab	1'7"
	Yuag	2205 lb

	NUV thaiv 27.5 USt (25 Mt)
	Ntev	5'10"
	Dav	2'11"
	Qhov siab	1'2"
	Yuag	1235 lb

	NUV pob 10 USt (9 Mt)
	Ntev	3'1"
	Dav	1'2"
	Qhov siab	1'2"
	Yuag	750 lb
TSAB NTAWV: 1. cov thauj qhov ntev ntawm tus xeem ntawv ntawm schematic kos duab, tiam sis tsis twv mus teev; lub qhov ntev qhia yog tus tsim qhov tseem ceeb excluding pob. 2. muaj ceeb thawj yog tus tsim nqi thiab tej zaum yuav muaj qhov sib txawv ntawm cov raug yuam kev.
