Product Description

SAMWAY SCC8068 Crawler Crane

• Engine: Cummins QSC8.3, 245 hp @ 2000 rpm

• Hydraulic system: Rexroth pumps and drive motors

• SAMWAY-designed LMI with large display screen

• Extendable tracks

• Two configurations available: Main Boom and Fixed Jib

• Main boom available in Tubular and Angle construction

KEY FEATURES

Maximum Capacity @ Radius	75 U.S. T @ 12.5 ft
Main Boom	3,6 & 9 Meter Sections 42 ft 8 in. – 219 ft 10 in.
Max Tip Height (H Main Boom)	223 ft
Fixed Jib Length	29 ft 6 in. – 59 ft 1 in.
Main Winch - Rated Line Pull	20,944 lb
Wire Rope Diameter	24 mm
Weight Basic Machine (Without Track Frames & With Boom Butt)	99,206 lb
Total Counterweight (Series 2)	82,450 lb
Length Basic Machine - Transport (With Track Frames & Boom Butt)	43 ft 4 in.
Height Basic Machine - Transport (With Track Frames & Boom Butt)	11 ft 5 in.
Width Basic Machine - Transport (With Track Frames & Boom Butt)	11 ft 4 in.
Tail Swing	16 ft 5 in

TRANSPORT DIMENSIONS

	BASE MACHINE (With Track Frame)
	Length	43'4"
	Width	11'4"
	Height	11'5"
	Weight	99206 lb

	BASE MACHINE (Without Track Frame)
	Length	26'2"
	Width	11'
	Height	10'
	Weight	55115 lb

	TRACK FRAME
	Length	20'8"
	Width	3'7"
	Height	3'11"
	Weight	20944 lb

	BOOM BASE
	Length	22'1"
	Width	5'3"
	Height	7'2"
	Weight Tubular Boom	3726 lb
	Weight Angle Boom	3748 lb

	BOOM TIP
	Length	23'4"
	Width	5'3"
	Height	5'9"
	Weight Tubular Boom	3241 lb
	Weight Angle Boom	3190 lb

	BOOM INSERT 9'10" (3m)
	Length	10'4"
	Width	5'6"
	Height	5'5"
	Weight Tubular Boom	1014 lb
	Weight Angle Boom	1378 lb

	BOOM INSERT 19'8" (6m)
	Length	20'2"
	Width	5'3"
	Height	5'5"
	Weight Tubular Boom	1631 lb
	Weight Angle Boom	2173 lb

	BOOM INSERT 29'6" (9m) No. 1
	Length	30'
	Width	5'3"
	Height	5'5"
	Weight Tubular Boom	2072 lb
	Weight Angle Boom	3057 lb

	BOOM INSERT 29'6" (9m) No. 2
	Length	30'
	Width	5'3"
	Height	5'5"
	Weight Tubular Boom	2072 lb
	*Not Available in Angle Boom

	FIXED JIB TIP 14'9" (4.5m)
	Length	16'
	Width	2'10"
	Height	2'6"
	Weight	728 lb

	FIXED JIB BASE 14'9" (4.5m)
	Length	15'6"
	Width	2'11"
	Height	2'6"
	Weight	661 lb

	FIXED JIB INSERT 14'9" (4.5m)
	Length	15'
	Width	2'10"
	Height	2'6"
	Weight	507 lb

	UPPER BOOM POINT
	Length	6'2"
	Width	2'5"
	Height	2'1"
	Weight Tubular Boom	375 lb
	Weight Angle Boom	375 lb

	CRAWLER SIDE COUNTERWEIGHT
	Length	12'5"
	Width	1'3"
	Height	2'5"
	Weight	11023 lb

	UPPERWORKS COUNTERWEIGHT TRAY
	Length	14'1"
	Width	5'3"
	Height	2'
	Weight	22046 lb

	COUNTERWEIGHT BLOCK
	Length	4'6"
	Width	3'7"
	Height	2'7"
	Weight	6393 lb

	HOOK BLOCK 55 USt (50 Mt)
	Length	6'6"
	Width	2'9"
	Height	1'7"
	Weight	2205 lb

	HOOK BLOCK 27.5 USt (25 Mt)
	Length	5'10"
	Width	2'11"
	Height	1'2"
	Weight	1235 lb

	HOOK BALL 10 USt (9 Mt)
	Length	3'1"
	Width	1'2"
	Height	1'2"
	Weight	750 lb
NOTES: 1. The transport dimensions of the parts marked on schematic diagrams, but not drawn to scale; the dimensions indicated are the design values excluding package. 2. The weight is the design value and there may be difference due to the manufacturing error.
