Samway PE88 Crimping Machine

Feature description

Vertical Crimping

+80mm Opening

Fast Crimping

Up to 6" Hose

Specification

Model

SAMWAY PE88

Crimping Range mm

 6"

Opening without die mm

275

Opening with die mm

+80

Crimping Force KN

8000

Master Die length mm

200

Crimping Method

Crimping up and down (No moving forward or backward make the positioning much easier )

Control

Mirco Dail or Digital control as an Option

Crimping Speed

Fast

Motor

3 phase by ABB ( 220/400/440/480/660V) 7.5KW

L*W*H mm

920*580*1200

Weight KG

1250

Standard Die Sets Included

Die No. 10* 12* 14 16 19 22 26 30 34 39 45 51 57 63 69 74* 78*

Length 55 55 55 55 55 55 75 75 90 90 90 90 90 100 100 100 100

* Optional Die Sets Upon Request

The SAMWAY PE88 models are the strongest table top machines in the SAMWAY general machine line.

Their wide opening makes it possible to crimp industrial hose up to 6″.

As there is no axial movement of the dies during the crimping, positioning is easy and accurate.

SAMWAY most simple operation experience make this much better crimping machine for hose with long or extra large flange.
